Temperature range: Room temperature + 2°C to 450°C  (using liquid CO2 gas: -50°C to 450°C)

Temperature program steps: Up to 32 (cooling program possible)

Injection Units: Maximum 3 independently temperature controlled injector units

Injection port unit: Split/splitless injection unit provided as standard.

 ◎Split/Splitless Injection Unit (SPL-2030):Temperature range: room temperature + 5°C to 450°C

 ◎Direct Injection Unit (WBI-2030)

 ◎On-column/Programmable Temperature Vaporizer Injection Unit (OCI/PTV-2030)

■ Detectors:

Four detectors can be installed simultaneously and individually temperature controlled.

◎Flame Ionization Detector (FID):Temperature range: to 450°C

   Minimum detected quantity: 1.2 pg C/s (dodecane)

◎Thermal Conductivity Detector (TCD):Temperature range: to 400°C

   Sensitivity: 20000 mV · mL/mg (decane)

◎Electron Capture Detector (ECD):Temperature range: to 400°C

    Minimum detected quantity: 4 fg/s (lindane)

◎Flame Photometric Detector (FPD): Temperature range: to 450°C

   Minimum detected quantity: P 45 fg P/s (tributyl phosphate) S 2 pgS/s (dodecane thiol)

◎Flame Thermionic Detector (FTD, also called NPD or TSD):Temperature range: to 450°C

  Minimum detected quantity: N 0.1 pg N/s (azobenzene)  P 0.01 pg P/s (malathion)

◎Barrier Discharge Ionization Detector (BID): Temperature range: to 350°C

  Minimum detected quantity: 0.8 pg C/s (dodecane)

■ Flow Control Unit

■ Split/splitless mode:

Pressure setting range: 0 to 1035 kPa

Programmable steps: 7 (pressure program possible)
