Item
|
UV-2600
|
|
Photometric system
|
Double-beam optics
|
|
Monochromator
|
Czerny-Turner mounting
Single monochromator
Lo-Ray-Ligh grade blazed holographic grating
|
|
Detector
|
R-928 photomultiplier
|
|
Light source
|
50 W halogen lamp, deuterium lamp, light source auto
position adjustment built in
|
|
Setting wavelength range
|
185 to 1400 nm
|
|
Measurement wavelength range
|
185 to 900 nm
220 to 1400 nm when the ISR-2600Plus Integrating
Sphere Attachment is used
|
|
Wavelength accuracy
|
0.1 nm (656.1 nm D2),0.3 nm (all range)
|
|
Wavelength repeatability
|
0.05 nm
|
|
Wavelength scanning speed
|
Wavelength slew rate: about 14000 nm/min
Wavelength scan rate: about 4000 to 0.5 nm/min
|
|
Wavelength setting
|
At 1 nm units for scan start and scan end
wavelengths, and 0.1 nm units for other wavelengths
|
|
Sample compartment
|
Automatic Accessory Recognition
200 (W) x 230 (L) x 170 (H) mm
Center Focus
|
|
Lamp interchange wavelength
|
Auto switching synchronized with wavelength; switching
range selectable between 290 and 370 nm (0.1 nm step)
|
|
Spectral bandwidth
|
0.1, 0.2, 0.5, 1, 2, 5 nm
L2/L5 (low stray-light mode)
|
|
Resolution
|
0.1 nm
|
|
Stray light
|
Max. 0.005 % (220 nm, NaI)
Max. 0.005 % (340, 370 nm, NaNO2)
Max. 1 % (198 nm, KCl)
|
|
Photometric modes
|
Absorbance (Abs), transmittance (%), reflectance (%),
energy (E)
Photometric range
Absorbance: -5 to 5 Abs
Transmittance, reflectance: 0 to 100000 %
|
|
Photometric accuracy
|
0.002 Abs (0.5 Abs)
0.003 Abs (1 Abs)
0.006 Abs (2 Abs)
0.3 %T
Measured using NIST930D/NIST1930 or equivalent filter
|
|
Photometric repeatability
|
0.001 Abs (0.5 Abs)
0.001 Abs (1 Abs)
0.003 Abs (2 Abs)
0.1 %T
|
|
Noise level
|
0.00003 Abs RMS (500 nm)
|
|
Baseline flatness
|
0.0003 Abs (200 to 860 nm), 1 hour after light
source is turned ON
|
|
Baseline stability
|
Within 0.0002 Abs/h (700 nm), 1 hour after
light source is turned ON
|
|
Sample compartment
|
Internal dimensions: W150 D260 H140
(mm)
Distance between light beams: 100 mm
Maximum optical path length of cell: 100 mm
|
|
Dimensions
|
W450 D600 H250 (mm)
|
|
Weight
|
23 kg
|
|
Operating temperature
|
15 to 35 C
|
|
Operating humidity
|
30 to 80 % (no condensation, less than 70 %
above 30 C)
|
|
Power requirements
|
100 to 240 VAC, 50/60 Hz
|
|
Power consumption
|
170 VA
|
